vertical lathes

N° 1 Vertical Lathe KDM 10-12

Rotating diameter mm. 1300

Max turning diameter mm. 1200

Max turning length mm. 800

Self-centering diameter mm. 1000

Speed rotation rpm. 600 600

2 ratios

Ram 220 x 220 stroke mm. 700

Fixed crossbar

16 positions tool change (8 turning + 8 ISO50 motorized)

C Axis

N° 1 Vertical Lathe KDM 12-16

Rotating diameter mm. 1700

Max turning diameter mm. 1600

Max turning length mm. 1150

Self-centering diameter mm. 1200

Speed rotation rpm. 300 300

2 ratios

Ram 240 x 240 stroke mm.900

Mobile crossbar 4 STEP each mm. 200

16 positions tool change (8 turning + 8 ISO50 motorized)

C Axis

N° 1 Vertical Lathe KDM 16-20

Rotating diameter mm. 2100

Max turning diameter mm. 2000

Max turning length mm. 1700

Self-centering diameter mm. 1600

Speed rotation rpm. 250 250

2 ratios

Ram 240 x 240 stroke mm. 1000

Mobile crossbar 4 STEP each mm. 250

16 positions tool change (8 turning + 8 ISO50 motorized)

C Axis

N° 1 Vertical Lathe Doosan VTR 16-20

Rotating diameter mm. 2100

Max turning diameter mm. 2100

Max turning length mm. 1750

Self-centering diameter mm. 1800

Speed rotation rpm. 250 250

Ram 250 x 250 stroke mm.1000

Mobile crossbar 4 STEP each mm. 250

16 positions tool change (8 turning + 8 ISO50 motorized)

C Axis

Head with 4 rotational positions at 90 degrees
